Danfoss VLT AutomationDrive FC 301 Programming Manual page 604

VLT AutomationDrive FC 301/302
Programming Guide
Option
[0]*
[1]
[2]
[3]
Parameter 33-21 Master Marker Tolerance Window
Table 1183: Parameter 33-21 Master Marker Tolerance Window
33-21 Master Marker Tolerance Window
Default value: 0
Conversion index: 0
Parameter 33-22 Slave Marker Tolerance Window
Table 1184: Parameter 33-22 Slave Marker Tolerance Window
33-22 Slave Marker Tolerance Window
Default value: 0
Conversion index: 0
Parameter 33-23 Start Behavior for Marker Sync
Table 1185: Parameter 33-23 Start Behavior for Marker Sync
33-23 Start Behavior for Marker Sync
Default value: [0] Leading marker
Conversion index: -
Option
[0]*
[1]
[2]
[3]
[4]
[5]
[6]
[7]
[1000]
[1001]
[1002]
[1003]
[1004]
604 | Danfoss A/S © 2022.12
Name
Encoder Z positive
Encoder Z negative
Ext. marker positive
Ext. marker negative
Parameter type: Range, 0 - 1073741823
Data type: Uint32
Parameter type: Range, 0 - 1073741823
Data type: Uint32
Parameter type: Option
Data type: Uint16
Name
Leading marker
Following marker
Closest marker
Master vel/ldg mrk
Master vel/flw mrk
Master vel/cls mrk
Next 2 markers
Start with poly5
Ldg mrk late offs
Flw mrk late offs
Cls mark late offs
Mv/ldg mrk/lt off
Mv/flw mrk/lt off
Parameter Descriptions
Description
Setup: 2 setups
Change during operation: True
Setup: 2 setups
Change during operation: True
Setup: 2 setups
Change during operation: True
Description
AU275636650261en-000101 / 130R0334
