Danfoss VLT AutomationDrive FC 301 Programming Manual page 171

VLT AutomationDrive FC 301/302
Programming Guide
Op- Name
tion
[4] Abs. Pos. Md.
Stop & Trip
[5] Position Stop
[6] Position Stop
& Trip
[7] Speed Stop
[8] Speed Stop &
Trip
Parameter 4-74 Start Fwd/Rev Function
Table 310: Parameter 4-74 Start Fwd/Rev Function
4-74 Start Fwd/Rev Function
Default value: [0] Stop
Conversion index: -
This parameter is only available with software version 48.XX.
Select the action that the drive executes when there is an active signal on a digital input with options [12] Enable Start Forward or
[13] Enable Start Reverse selected. The drive executes the function selected in this parameter when running into an end limit switch
and then the motion is only allowed in the opposite direction. When an option with trip is selected, the drive can resume motion
only after reset.
Option Name
[0]* Stop
[1] Stop & Warning
[2] Stop & Trip
[3] Qstop
[4] Qstop & Warning
[5] Qstop & Trip
[6] Coast
[7] Coast & Warning
[8] Coast & Trip
[9] Zero Speed Ref
[10] Zero Sp. Ref. & War.
Danfoss A/S © 2022.12
Description
The drive monitors position limits only in absolute positioning mode. The drive stops at the position
limit and trips when the target position is outside the position limits.
When the set target is outside the position limits, the drive uses the position limit as target. This op-
tion works in all modes of operation including speed and torque control. The drive issues a warning
when at limit position.
When the set target is outside the position limits, the drive uses the position limit as target. This op-
tion works in all modes of operation including speed and torque control. The drive trips when at limit
position.
When the set target is outside the position limits, the drive performs a ramp down and stops at the
limit position. This option works in all modes of operation. The drive issues a warning stop.
When the set target is outside the position limits, the drive performs a ramp down and stops at the
limit position. This option works in all modes of operation. The drive trips at stop.
Parameter type: Option
Data type: Uint8
N O T I C E
Description
The drive stops the motor.
The drive stops the motor and shows warning 215, Start Fwd/Rev.
The drive stops the motor and trips with alarm 215, Start Fwd/Rev.
The drive performs the quick stop.
The drive performs the quick stop and shows warning 215, Start Fwd/Rev.
The drive performs the quick stop and trips with alarm 215, Start Fwd/Rev.
The drive coasts the motor.
The drive coasts the motor and trips with warning 215, Start Fwd/Rev.
The drive coasts the motor and trips with alarm 215, Start Fwd/Rev.
The drive ramps down and keeps the motor magnetized at 0 speed. In the positioning and the
synchronization modes, the position controller stays active and retains the actual position.
Same as option [9] Zero Speed Ref and shows warning 215, Start Fwd/Rev.
Parameter Descriptions
Setup: All setups
Change during operation: True
AU275636650261en-000101 / 130R0334 | 171
