VLT AutomationDrive FC 301/302
Programming Guide
Option Name
[132] Feedback 4–
20mA
[133] Motor cur. 4–
20mA
[134] Torq.% lim 4–
20mA
[135] Torq.% nom 4–
20mA
[136] Power 4–20mA
[137] Speed 4–20mA
[138] Torque 4–20mA
[139] Bus ctrl.
[140] Bus ctrl. 4–20mA
[141] Bus ctrl t.o.
[142] Bus ctrl 4-20mA
t.o.
[147] Main act val
[148] Main act val
4-20mA
[149] Torque % lim
4-20mA
[150] Max Out Fr
4-20mA
[158] Motor Volt.
[159] Motor Volt.
4-20mA
Danfoss A/S © 2022.12
Description
The value is taken from parameter 16-37 Inv. Max. Current. The inverter maximum current (160%
current) is equal to 20 mA. Example: Inverter normal current (11 kW) is 24 A. 160% = 38.4 A. Motor
normal current is 22 A, the readout is 11.46 mA.
16 mA × 22 A
= 13 . 17 mA
38 . 4 A
If the normal motor current is equal to 20 mA, the output setting of parameter 6-52 Terminal 42
Output Max Scale is:
I × 100 38 . 4 × 100
VLT, MAX
=
I 22
Motor, Nom
The torque setting is related to the setting in parameter 4-16 Torque Limit Motor Mode.
The torque setting is related to the motor torque setting.
Taken from parameter 1-20 Motor Power [kW].
Taken from parameter 3-03 Maximum Reference. 20 mA = value in parameter 3-03 Maximum Refer-
ence.
Torque reference related to 160% torque.
An output value set from fieldbus process data. The output works independently of internal func-
tions in the drive.
An output value set from fieldbus process data. The output works independently of internal func-
tions in the drive.
Parameter 4-54 Warning Reference Low defines the behavior of the analog output in case of field-
bus timeout.
Parameter 4-54 Warning Reference Low defines the behavior of the analog output in case of field-
bus timeout.
Analog output at 0 torque is 12 mA. Motoring torque increases the output current to maximum
torque limit 20 mA (set in parameter 4-16 Torque Limit Motor Mode). Generating torque decreases
the output to torque limit in generator mode (set in parameter 4-17 Torque Limit Generator Mode)
Example: Parameter 4-16 Torque Limit Motor Mode = 200% and parameter 4-17 Torque Limit Genera-
tor Mode = 200%. 20 mA = 200% motoring and 4 mA = 200% generating.
0 Hz = 0 mA, parameter 4-19 Max Output Frequency = 20 mA.
= 175 %
