Danfoss VLT AutomationDrive FC 301 Programming Manual page 512

VLT AutomationDrive FC 301/302
Programming Guide
Parameter 16-79 Analog Out X45/3 [mA]
Table 893: Parameter 16-79 Analog Out X45/3 [mA]
16-79 Analog Out X45/3 [mA]
Default value: 0
Conversion index: -3
Shows the actual output value at terminal X45/3. The value shown reflects the selection in parameter 6-80 Terminal X45/3 Output.
5.16.6 16-8* Fieldbus & FC Port
Parameter 16-80 Fieldbus CTW 1
Table 894: Parameter 16-80 Fieldbus CTW 1
16-80 Fieldbus CTW 1
Default value: 0
Conversion index: 0
View the 2-byte control word (CTW) received from the bus-master. Interpretation of the CTW depends on the fieldbus option instal-
led and the CTW profile selected in parameter 8-10 Control Word Profile. For more information, refer to the relevant fieldbus manual.
Parameter 16-82 Fieldbus REF 1
Table 895: Parameter 16-82 Fieldbus REF 1
16-82 Fieldbus REF 1
Default value: 0
Conversion index: 0
View the 2-byte word sent with the control word form the bus-master to set the reference value. For more information, refer to the
relevant fieldbus manual.
Table 896: Parameter 16-83 Fieldbus Pos. REF
16-83 Fieldbus Pos. REF
Default value: 0 Custom- ReadoutUni t2
Conversion index: 0
This parameter is only valid with software 48.XX.
Shows the 32-bit position reference sent in PCD 2 and PCD 3. In parameters related to PCD 2 and PCD 3, select [1683] Fieldbus Pos
REF for the fieldbus which is used by the drive. The value is in position units defined in parameter group 17-7* Position Scaling.
Parameter 16-84 Comm. Option STW
Table 897: Parameter 16-84 Comm. Option STW
16-84 Comm. Option STW
Default value: 0
Conversion index: 0
Show the status word of the extended fieldbus communication option. For more information, refer to the relevant fieldbus manual.
512 | Danfoss A/S © 2022.12
Parameter type: Range, 0 - 30
Data type: Int16
Parameter type: Range, 0 - 65535
Data type: V2
Parameter type: Range, -200 - 200
Data type: N2
Parameter type: Range, -2147483648 - 2147483647
CustomReadoutUnit2
Data type: N2
N O T I C E
Parameter type: Range, 0 - 65535
Data type: V2
Parameter Descriptions
Setup: All setups
Change during operation: False
Setup: All setups
Change during operation: False
Setup: All setups
Change during operation: False
Setup: All setups
Change during operation: False
Setup: All setups
Change during operation: False
AU275636650261en-000101 / 130R0334
