Danfoss VLT AutomationDrive FC 301 Programming Manual page 299

VLT AutomationDrive FC 301/302
Programming Guide
Option Name
[0] Digital input
[1] Bus
[2] Logic AND
[3]* Logic OR
Parameter 8-51 Quick Stop Select
Table 528: Parameter 8-51 Quick Stop Select
8-51 Quick Stop Select
Default value: [3] Logic OR
Conversion index: –
Select the trigger for the quick stop function.
Option Name
[0] Digital input
[1] Bus
[2] Logic AND
[3]* Logic OR
Parameter 8-52 DC Brake Select
Table 529: Parameter 8-52 DC Brake Select
8-52 DC Brake Select
Default value: Size related
Conversion index: –
Select control of the DC brake via the terminals (digital input) and/or via the fieldbus.
When parameter 1-10 Motor Construction is set to [1] PM non-salient SPM, only selection [0] Digital input is available.
Option Name Description
[0] Digital input Activate a start command via a digital input.
[1] Bus Activate a start command via a serial communication port or fieldbus option.
[2] Logic AND Activate a start command via the fieldbus/serial communication port and also via 1 of the digital inputs.
[3] Logic OR Activate a start command via the fieldbus/serial communication port or via 1 of the digital inputs.
Danfoss A/S © 2022.12
Description
A digital input triggers the coasting function.
A serial communication port or the fieldbus triggers the coasting function.
The fieldbus/serial communication port and a digital input trigger the coasting function.
The fieldbus/serial communication port or a digital input triggers the coasting function.
Parameter type: Option
Data type: Uint8
Description
A digital input triggers the quick stop function.
A serial communication port or the fieldbus triggers the quick stop function.
The fieldbus/serial communication port and a digital input trigger the quick stop function.
The fieldbus/serial communication port or a digital input triggers the quick stop function.
Parameter type: Option
Data type: Uint8
N O T I C E
Parameter Descriptions
Setup: All setups
Change during operation: True
Setup: All setups
Change during operation: True
AU275636650261en-000101 / 130R0334 | 299
