Danfoss VLT AutomationDrive FC 301 Programming Manual page 221

VLT AutomationDrive FC 301/302
Programming Guide
Table 374: Options for Readout Output Variables
Option Name
[0] No operation
[45] Bus control
[48] Bus control timeout
[51] MCO-controlled
[97] Reference after ramp
[99] Virtual master speed
[100] Output frequency
[101] Reference
[102] Feedback
[103] Motor current
[104] Torque relative to limit
[105] Torque relative to rated
[106] Power
[107] Speed
[108] Torque
[109] Max. out freq
Parameter 5-60 Terminal 27 Pulse Output Variable
Table 375: Parameter 5-60 Terminal 27 Pulse Output Variable
5-60 Terminal 27 Pulse Output Variable
Default value: Size related
Conversion index: –
Danfoss A/S © 2022.12
Description
Parameters for configuring the scaling and output functions of pulse outputs. The pulse out-
puts are designated to terminals 27 or 29. Select terminal 27 output in parameter 5-01 Termi-
nal 27 Mode and terminal 29 output in parameter 5-02 Terminal 29 Mode.
This option is available only with software version 48.XX.
Actual speed reference after the ramp. Use this output as master signal for speed synchroni-
zation of follower drives. The reference is set in parameter 16-48 Speed Ref. After Ramp [RPM].
This option is only available with software version 48.XX.
Virtual master signal for controlling the speed or position the followers.
Parameter type: Option
Data type: Uint8
N O T I C E
N O T I C E
Setup: All setups
Change during operation: True
AU275636650261en-000101 / 130R0334 | 221
Parameter Descriptions
