Danfoss VLT AutomationDrive FC 301 Programming Manual page 383

VLT AutomationDrive FC 301/302
Programming Guide
Option Name
[45] Analog input X49/5
[50] FALSE
[51] TRUE
[52] Control ready
[53] Drive ready
[54] Running
[55] Reversing
[56] In range
[60] On reference
[61] Below reference, low
[62] Above ref, high
[65] Torque limit
[66] Current limit
[67] Out of current range
[68] Below I low
[69] Above I high
[70] Out of speed range
[71] Below speed low
[72] Above speed high
[75] Out of feedack range
[76] Below feedback low
[77] Above feedback high
[80] Thermal warning
[82] Mains out of range
[85] Warning
[86] Alarm (trip)
[87] Alarm (trip lock)
[90] Bus OK
Danfoss A/S © 2022.12
Description
Use to enter the fixed value False in the comparator.
Use to enter True in the comparator.
The control board receives supply voltage.
The drive is ready for operation and applies a signal on the control board.
The motor runs.
The output is active when the drive runs counterclockwise (the logical product of the status
bits running AND reverse).
The motor runs within the programmed current and speed ranges set in parameter 4-50 Warn-
ing Current Low to parameter 4-53 Warning Speed High.
The motor runs on reference.
The motor runs at a reference which is less than the value in parameter 4-54 Warning Reference
Low.
The motor runs at a reference which exceeds the value in parameter 4-55 Warning Reference
High.
The torque exceeds the value in parameter 4-16 Torque Limit Motor Mode or parameter 4-17 Tor-
que Limit Generator Mode.
The motor current exceeds the value in parameter 4-18 Current Limit.
The motor current is outside the range set in parameter 4-18 Current Limit.
The motor current is lower than the value in parameter 4-50 Warning Current Low.
The motor current is higher than the value in parameter 4-51 Warning Current High.
The speed is outside the range set in parameter 4-52 Warning Speed Low and parameter 4-53
Warning Speed High.
The output speed is lower than the value in parameter 4-52 Warning Speed Low.
The output speed is higher than the value in parameter 4-53 Warning Speed High.
The feedback is outside the range set in parameter 4-56 Warning Feedback Low and parameter
4-57 Warning Feedback High.
The feedback is lower than the limit set in parameter 4-56 Warning Feedback Low.
The feedback exceeds the limit set in parameter 4-57 Warning Feedback High.
This operand becomes true when the drive detects any thermal warning, for instance when the
temperature exceeds the limit in the motor, the drive, the brake resistor, or thermistor.
The mains voltage is outside the specified voltage range.
If a warning is triggered, this operand gets the warning number.
A trip alarm is active.
A trip lock alarm is active.
Active communication (no timeout) via the serial communication port.
Parameter Descriptions
AU275636650261en-000101 / 130R0334 | 383
