Option Name
[31] SL time-out 1
[32] SL time-out 2
[33] Digital input DI18
[34] Digital input DI19
[35] Digital input DI27
[36] Digital input DI29
[37] Digital input DI32
[38] Digital input DI33
[39] Start command
[40] Drive stopped
[41] Reset trip
[42] Auto-reset trip
[43] OK key
[44] Reset key
[45] Left key
[46] Right key
[47] Up key
[48] Down key
[50] Comparator 4
[51] Comparator 5
[60] Logic rule 4
[61] Logic rule 5
[70] SL time-out 3
[71] SL time-out 4
[72] SL time-out 5
[73] SL time-out 6
[74] SL time-out 7
[75] Start command given
[76] Digital input X30/2
[77] Digital input X30/3
Danfoss A/S © 2022.12
Description
This option is only available in FC 302.
[OK] is pressed. Only available on the graphical LCP.
[Reset] is pressed. Only available on the graphical LCP.
[◃] is pressed. Only available on the graphical LCP.
[▹] is pressed. Only available on the graphical LCP.
[▵] is pressed. Only available on the graphical LCP.
[▿] is pressed. Only available on the graphical LCP.
Use the result of comparator 4.
Use the result of comparator 5.
Use the result of logic rule 4.
Use the result of logic rule 5.
