VLT AutomationDrive FC 301/302
Programming Guide
Option Name
[0] No operation
[1] Control ready
[2] Drive ready
[3] Drive rdy/rem ctrl
[4] Enable/no warning
[5] Running
[6] Running/no warning
[7] Run in range/no warn
[8] Run on ref/no warn
[9] Alarm
[10] Alarm or warning
[11] At torque limit
[12] Out of current range
[13] Below current, low
[14] Above current, high
[15] Out of speed range
[16] Below speed, low
[17] Above speed, high
[18] Out of feedb. range
[19] Below feedback, low
[20] Above feedback, high
[21] Thermal warning
[22] Ready,no thermal W
[23] Remote,ready, no TW
[24] Ready, Voltage OK
[25] Reverse
[26] Bus OK
210 | Danfoss A/S © 2022.12
Description
All digital and relay outputs are by default set to No Operation.
The control card is ready.
The drive is ready to operate. Mains and control supplies are OK.
The drive is ready for operation and is in auto-on mode.
Ready for operation. No start or stop commands have been applied (start/disable). No warn-
ings are active.
The motor is running, and shaft torque is present.
Output speed is higher than the speed set in parameter 1-81 Min Speed for Function at Stop
[RPM]. The motor runs and there are no warnings.
The motor runs within the programmed current and the speed ranges set in parameter 4-50
Warning Current Low and parameter 4-53 Warning Speed High. No warnings.
The motor runs at reference speed. No warnings.
An alarm activates the output. No warnings.
An alarm or a warning activates the output.
The torque limit set in parameter 4-16 Torque Limit Motor Mode or parameter 4-17 Torque Limit
Generator Mode has been exceeded.
The motor current is outside the range set in parameter 4-18 Current Limit.
The motor current is lower than set in parameter 4-50 Warning Current Low.
The motor current is higher than set in parameter 4-51 Warning Current High.
Output speed/frequency is outside the frequency range set in parameter 4-52 Warning Speed
Low and parameter 4-53 Warning Speed High.
Output speed is lower than the setting in parameter 4-52 Warning Speed Low.
Output speed is higher than the setting in parameter 4-53 Warning Speed High.
Feedback is outside the range set in parameter 4-56 Warning Feedback Low and parameter
4-57 Warning Feedback High.
Feedback is below the limit set in parameter 4-56 Warning Feedback Low.
Feedback is above the limit set in parameter 4-57 Warning Feedback High.
Thermal warning turns on when the temperature exceeds the limit either in motor, drive,
brake resistor, or connected thermistor.
The drive is ready for operation and there is no overtemperature warning.
The drive is ready for operation and is in auto-on mode. There is no overtemperature warn-
ing.
The drive is ready for operation and the mains voltage is within the specified voltage range.
The motor runs (or is ready to run) clockwise when logic = 0 and counterclockwise when log-
ic = 1. The output changes as soon as the reversing signal is applied.
Active communication (no timeout) via the serial communication port.
Parameter Descriptions
