VLT AutomationDrive FC 301/302
Programming Guide
Parameter 16-31 System Temp.
Table 849: Parameter 16-31 System Temp.
16-31 System Temp.
Default value: 0 °C
Conversion index: 100
Shows the highest internal system temperature. In the smaller enclosure sizes (A–C), the system temperature matches the control
card temperature measurement in parameter 16-39 Control Card Temp. In the larger enclosure sizes (D–F), the system temperature is
the highest temperature measured on hardware components with temperature sensors, for example, the power card(s).
Parameter 16-32 Brake Energy /s
Table 850: Parameter 16-32 Brake Energy /s
16-32 Brake Energy /s
Default value: 0 kW
Conversion index: 0
View the brake power transmitted to an external brake resistor, stated as an instant value.
Parameter 16-33 Brake Energy Average
Table 851: Parameter 16-33 Brake Energy Average
16-33 Brake Energy Average
Default value: 0 kW
Conversion index: 0
View the brake power transmitted to an external brake resistor. The mean power is calculated on an average level based on the
selected time period within parameter 2-13 Brake Power Monitoring.
Parameter 16-34 Heatsink Temp.
Table 852: Parameter 16-34 Heatsink Temp.
16-34 Heatsink Temp.
Default value: 0 °C
Conversion index: 100
View the drive heat sink temperature. The cutout limit is 90 ±5 °C (194 ±9 °F), and the motor cuts back in at 60 ±5 °C (140 ±9 °F).
Parameter 16-35 Inverter Thermal
Table 853: Parameter 16-35 Inverter Thermal
16-35 Inverter Thermal
Default value: 0%
Conversion index: 0
View the percentage load on the inverter.
502 | Danfoss A/S © 2022.12
Parameter type: Range, -128 - 127 °C
Data type: Int8
Parameter type: Range, 0 - 10000 kW
Data type: Uint32
Parameter type: Range, 0 - 10000 kW
Data type: Uint32
Parameter type: Range, 0 - 255 °C
Data type: Uint8
Parameter type: Range, 0 - 100%
Data type: Uint8
Parameter Descriptions
Setup: All setups
Change during operation: True
Setup: All setups
Change during operation: False
Setup: All setups
Change during operation: False
Setup: All setups
Change during operation: False
Setup: All setups
Change during operation: False
AU275636650261en-000101 / 130R0334
