VLT AutomationDrive FC 301/302
Programming Guide
Parameter 1-10 Motor Construction
Table 69: Parameter 1-10 Motor Construction
1-10 Motor Construction
Default value: [0] Asynchron
Conversion index: –
Select the motor design type.
FC 301 allows only selection of induction motors.
Option Name
[0]* Asynchron
[1] PM, non sali-
ent SPM
[2] PM, salient
IPM
[5] SynRM
[6] PMaSynRM
Parameter 1-11 Motor Model
Table 70: Parameter 1-11 Motor Model
1-11 Motor Model
Default value: Size related
Conversion index: –
Automatically sets the factory values for the selected motor. If the default value [1] Std. Asynchron is used, determine settings man-
ually according to the selection in parameter 1-10 Motor Construction.
There are no models available for SynRM motors.
Danfoss A/S © 2022.12
Parameter type: Option
Data type: Uint8
N O T I C E
Description
Use for ASM/IM motors.
This option is only available in FC 302.
Use for SPM motors, surface-mounted magnet. PM motors are divided into 2 groups, with either sur-
face-mounted (SPM)/non-salient magnets or interior-mounted (IPM)/ salient magnets.
This option is only available in FC 302.
Use for IPM motors, interior-mounted magnet. PM motors are divided into 2 groups, with either sur-
face-mounted (SPM)/non-salient magnets or interior-mounted (IPM)/ salient magnets.
Use for SynRM, synchronous reluctance motors.
Use for PMaSynRM, Permanent Magnet assisted synchronous reluctance motors.
Parameter type: Option
Data type: Uint8
N O T I C E
Setup: All setups
Change during operation: False
N O T I C E
N O T I C E
Setup: All setups
Change during operation: False
AU275636650261en-000101 / 130R0334 | 73
Parameter Descriptions
