VLT AutomationDrive FC 301/302
Programming Guide
Bit Description
22 Reserved
23 Reserved
24 Loop port 0
25 Communication on port 0
26 Loop port 1
27 Communication on port 1
28 Reserved
29 Reserved
30 Reserved
31 Reserved
5.12.8 12-6* Ethernet POWERLINK
Parameter 12-60 Node ID
Table 646: Parameter 12-60 Node ID
12-60 Node ID
Default value: 1
Conversion index: 0
Enter the node ID in this parameter or alternatively in the hardware switch. To adjust the node ID in this parameter, set the hard-
ware switch to 0 or to 255 (all switches set to [ON] or to [OFF]). Otherwise, this parameter shows the actual setting of the switch. The
settings of this parameter take effect at the next power-up cycle.
Table 647: Parameter 12-62 SDO Timeout
12-62 SDO Timeout
Default value: 15000
Conversion index: -3
This parameter is the SDO Timeout in ms. The value of this parameter is read during communication initialization into Object 1300h.
Parameter 12-63 Basic Ethernet Timeout
Table 648: Parameter 12-63 Basic Ethernet Timeout
12-63 Basic Ethernet Timeout
Default value: 5000.000
Conversion index: -3
This parameter is the basic Ethernet timeout in ms. This parameter is mapped to Object 1F99h. If the POWERLINK interface does not
receive a SoC frame within the specified time, the interface shifts to standard Ethernet mode. This feature is available from version
2.00 of the POWERLINK interface.
366 | Danfoss A/S © 2022.12
Bit = [0]
–
–
Open
No stable communication
Open
No stable communication
–
–
–
–
Parameter type: Range, 1 - 239
Data type: Uint8
Parameter type: Range, 0 - 2000000000
Data type: Uint32
Parameter type: Range, 0 - 2000000.000 ms
Data type: Uint32
Parameter Descriptions
Bit = [1]
–
–
Closed
Communication established
Closed
Communication established
–
–
–
–
Setup: 2 setups
Change during operation: True
Setup: All setups
Change during operation: True
Setup: All setups
Change during operation: True
AU275636650261en-000101 / 130R0334
