Danfoss VLT AutomationDrive FC 301 Programming Manual page 198

VLT AutomationDrive FC 301/302
Programming Guide
Parameter 5-24 Terminal X46/9 Digital Input
Table 350: Parameter 5-24 Terminal X46/9 Digital Input
5-24 Terminal X46/9 Digital Input
Default value: [0] No operation
Conversion index: –
The options for this parameter are the same as those listed for parameter 5-20 Terminal X46/1 Digital Input.
Parameter 5-25 Terminal X46/11 Digital Input
Table 351: Parameter 5-25 Terminal X46/11 Digital Input
5-25 Terminal X46/11 Digital Input
Default value: [0] No operation
Conversion index: –
The options for this parameter are the same as those listed for parameter 5-20 Terminal X46/1 Digital Input.
Parameter 5-26 Terminal X46/13 Digital Input
Table 352: Parameter 5-26 Terminal X46/13 Digital Input
5-26 Terminal X46/13 Digital Input
Default value: [0] No operation
Conversion index: –
The options for this parameter are the same as those listed for parameter 5-20 Terminal X46/1 Digital Input.
5.6.3 5-3* Digital Outputs
The following parameter is only available in FC 302:
-
Parameter 5-31 Terminal 29 Digital Output
The 2 solid-state digital outputs are common for terminals 27 and 29. Set the I/O function for terminal 27 in parameter 5-01 Terminal
27 Mode, and set the I/O function for terminal 29 in parameter 5-02 Terminal 29 Mode.
These parameters cannot be adjusted while the motor is running.
Table 353: Digital Outputs, Function Descriptions - 1
Option
[0] No operation
[1] Control ready
[2] Drive ready
[3] Drive rdy/rem ctrl
[4] Enable/no warning
[5] Running
198 | Danfoss A/S © 2022.12
Parameter type: Option
Data type: Uint8
Parameter type: Option
Data type: Uint8
Parameter type: Option
Data type: Uint8
N O T I C E
N O T I C E
Function
Default for all digital outputs and relay outputs.
The control card is ready.
The drive is ready for operation and applies a supply signal on the control card.
The drive is ready for operation and is in auto-on mode.
Ready for operation. No start or stop command has been given (start/disable). No warnings are
active.
The motor runs, and shaft torque is present.
Parameter Descriptions
Setup: All setups
Change during operation: True
Setup: All setups
Change during operation: True
Setup: All setups
Change during operation: True
AU275636650261en-000101 / 130R0334
