VLT AutomationDrive FC 301/302
Programming Guide
Option Name
[233] In Power Limit
[234] PE power off
[246] Emcy mode was act.
[247] Emergency mode
[249] Emcy m. OPR unexpected
[250] Emcy mode limits
[254] Testing emcy mode
Parameter 5-31 Terminal 29 Digital Output
Table 357: Parameter 5-31 Terminal 29 Digital Output
5-31 Terminal 29 Digital Output
Default value: Size related
Conversion index: –
The options for this parameter are the same as those listed for parameter 5-30 Terminal 27 Digital Output.
Parameter 5-32 Term X30/6 Digi Out (MCB 101)
Table 358: Parameter 5-32 Term X30/6 Digi Out (MCB 101)
5-32 Term X30/6 Digi Out (MCB 101)
Default value: Size related
Conversion index: –
This parameter is active when option module VLT® General Purpose I/O MCB 101 is mounted in the drive. The options for this pa-
rameter are the same as those listed for parameter 5-30 Terminal 27 Digital Output.
Table 359: Parameter 5-33 Term X30/7 Digi Out (MCB 101)
5-33 Term X30/7 Digi Out (MCB 101)
Default value: Size related
Conversion index: –
This parameter is active when option module VLT® General Purpose I/O MCB 101 is mounted in the drive. The options for this pa-
rameter are the same as those listed for parameter 5-30 Terminal 27 Digital Output.
5.6.4 5-4* Relays
Parameters for configuring the timing and the output functions for the relays.
Parameter 5-40 Function Relay
Table 360: Parameter 5-40 Function Relay
5-40 Function Relay
Default value: Size related
Conversion index: –
Select options to define the function of the relays. Relay 1 [0], relay 2 [1]. With VLT® Extended Relay Card MCB 113 installed: Relay 3
[2], Relay 4 [3], Relay 5 [4], Relay 6 [5]. With VLT® Relay Card MCB 105 installed: Relay 7 [6], relay 8 [7], Relay 9 [8].
Danfoss A/S © 2022.12
Parameter type: Option
Data type: Uint8
Parameter type: Option
Data type: Uint8
Parameter type: Option
Data type: Uint8
Parameter type: Option, Array [9]
Data type: Uint8
Parameter Descriptions
Description
Setup: All setups
Change during operation: True
Setup: All setups
Change during operation: True
Setup: All setups
Change during operation: True
Setup: All setups
Change during operation: True
