Parameter 17-10 Signal Type
Table 915: Parameter 17-10 Signal Type
17-10 Signal Type
Default value: [1] RS422 (5V TTL)
Conversion index: -
Select this parameter if 1 or 2 encoders are connected to MCB 102.
Option
[0]
[1]*
[2]
Parameter 17-11 Resolution (PPR)
Table 916: Parameter 17-11 Resolution (PPR)
17-11 Resolution (PPR)
Default value: 1024
Conversion index: 0
Enter the number of pulses or periods per revolution (the incremental track).
5.17.3 17-2* Abs. Enc. Interface
Parameters in this group configure the absolute interface of the VLT® Encoder Input MCB 102. Both the incremental and absolute
interfaces are active at the same time.
Parameter 17-20 Protocol Selection
Table 917: Parameter 17-20 Protocol Selection
17-20 Protocol Selection
Default value: [0] None
Conversion index: -
This parameter cannot be adjusted while the motor is running.
Option Name
[0]* None
[1] HIPERFACE
[2] EnDat
[4] SSI
[8] Z pulse
518 | Danfoss A/S © 2022.12
Parameter type: Option
Data type: Uint8
Name
None
RS422 (5V TTL)
Sinosoidal 1Vpp
Parameter type: Range, 10 - 16384
Data type: Uint16
Parameter type: Option
Data type: Uint8
N O T I C E
Description
Select [0] None if the feedback sensor is an incremental encoder only.
Select [1] HIPERFACE if the encoder is absolute only.
Select 0 pulse as "absolute" track when using incremental encoder with 0 pulse.
Parameter Descriptions
Setup: All setups
Change during operation: False
Description
Setup: All setups
Change during operation: False
Setup: All setups
Change during operation: False
AU275636650261en-000101 / 130R0334
