VLT AutomationDrive FC 301/302
Programming Guide
Option Name
[227] Touch activated
[228] Comparator 6
[229] Comparator 7
[230] Comparator 8
[231] Comparator 9
[232] Logic rule 6
[233] Logic rule 7
[234] Logic rule 8
[235] Logic rule 9
[236] SL time-out 8
[237] SL time-out 9
[238] RS flipflop 8
[239] RS flipflop 9
[240] SL digital output A
[241] SL digital output B
[242] SL digital output C
[243] SL digital output D
[244] SL digital output E
[245] SL digital output F
Parameter 13-43 Logic Rule Operator 2
Table 684: Parameter 13-43 Logic Rule Operator 2
13-43 Logic Rule Operator 2
Default value: Size related
Conversion index: -
nd
Select the 2 logical operator to be used on the boolean input calculated in:
•
Parameter 13-40 Logic Rule Boolean 1.
•
Parameter 13-41 Logic Rule Operator 1.
• Parameter 13-42 Logic Rule Boolean 2.
[13-44] signifies the boolean input of parameter 13-44 Logic Rule Boolean 3. [13-40/13-42] signifies the boolean input calculated in:
• Parameter 13-40 Logic Rule Boolean 1.
•
Parameter 13-41 Logic Rule Operator 1.
• Parameter 13-42 Logic Rule Boolean 2.
408 | Danfoss A/S © 2022.12
Description
Target position is reached in touch probe position mode.
Touch probe positioning is active. The drive monitors the touch probe sensor input.
Parameter type: Option, Array [10]
Data type: Uint8
Parameter Descriptions
Setup: 2 setups
Change during operation: True
AU275636650261en-000101 / 130R0334
