GE Healthcare
Revision 1
Functional Diagrams
12-5. Control Station Power Distribution Diagram (CS V1/V2)
AC Module
Note:
Not present on later models
with an internal CD‐W unit.
CD‐W
Monitor
AC
ETHERNET
SWITCH
Chapter 3
AC
IN
UPS
AC
Service Information and Procedures Class A 2385072-16-8EN
AC
Module
AC
AC
AC
AC
Boards 2
AC
SCSI
IN
RJ45
Internal
Ethernet
OUT
AC
AC
AC
AC
AC
IDC
OF
SIB
26Pts
SIB
50Pts
Page no. 86
Serial
Modem
PCI
& 1
1
1
USB
USB
2
2
ADS
AC
COM1
RJ45
COM2
Senographe DS
FunctionsDS.fm
- Quick Links:
- Err Sub A001 - Generator Error...
Hide quick links:
Advertisement
Table of Contents
Troubleshooting
Need help?
Do you have a question about the Senographe DS and is the answer not in the manual?
Questions and answers
G.E.Essential l have recently bought What is the full weight.of the mamo Full weight of the console and other İtem's also measurements of each item with the main machine please All this Shipping Company required
The GE Senographe DS mammography machine is shipped in three crates with the following dimensions and weights:
- Crate 1 (Gantry, Generator Cabinet, and ramp):
- Dimensions: 2066 mm (81.34 in) depth × 848 mm (33.39 in) width × 2292 mm (90.24 in) height
- Mass: 641 kg (1410.2 lbs)
- Crate 2 (Control Station):
- Dimensions: 1110 mm (43.70 in) depth × 770 mm (30.31 in) width × 1850 mm (72.83 in) height
- Mass: 210.5 kg (464.07 lbs) for truck transport (without side covers and lid)
- Mass: 223.5 kg (492.73 lbs) for plane/boat transport (with side covers and lid)
- Crate 3 (Detector):
- Dimensions: 872 mm (34.33 in) depth × 2270 mm (89.37 in) width × 260 mm (10.24 in) height
- Mass: 104.4 kg (229.68 lbs)
### Total Mass:
- For truck transport: 641 + 210.5 + 104.4 = 955.9 kg (2104.95 lbs)
- For plane/boat transport: 641 + 223.5 + 104.4 = 968.9 kg (2133.61 lbs)
These values include the gantry, generator cabinet, control station, detector, and all related components.
