GE Senographe DS Manual page 102

GE Healthcare
Revision 1
Senographe Operations - How to...
ILLUSTRATION 2 -
WARNING
TYPE OF TUBE 2foc/2met/1ang
FOCUS ANODE
TYPE OF ANODE 2Metal
DM SMSA
FOCUS SELECTION bifocus
SINGLE DUAL
MODEL OF TUBE : (Maxray 100TH-M1)
GS412 70TH-F
GS412 70TH-F
VALID VALID
Chapter 3
CHECKSUM OF SAVED PARAM
CKSUM CLEAR
USING THE CLEAR FUNCTION WILL
ENTAIL A COMPLETE RE-CALIBRATION
OF THE GANTRY, GENERATOR AND AEC.
CLEAR ALL SAVED PARAM
VALID
MAX AUTHORIZED POWER POWE = (value)
3.0KW 3.5KW
MODEL DCHARG
SMDA
X-RAY DISCHARGE Delay (ms)
NEXT
100TH-M1
70TH-D
70TH-D 100TH-M1
VALID
VALID
ARM PRESENCE
YES
Service Information and Procedures Class A 2385072-16-8EN
APPLICATION MODE
GENERATOR CONFIGURATION
TUBE PMAX MASMAX
4.0KW 4.5KW 5.0KW
MAX MAS ALLOWED mAs=(value)
NEXT VALID
VALID
SUB-SYSTEMS PRESENCE
PRS-B PRS-DS
DIGITAL STATION PRESENCE
NO YES
Page no. 102
PRES. T_MAX RINIT
WARNING
RE-INITIALIZING THE TUBE
WILL ENTAIL RE-CALIBRATING
THE TUBE HEATER CURRENT.
USE THE FUNCTION ONLY
WHEN YOU HAVE REPLACED
THE X-RAY TUBE.
MAX EXPOSURE TIME T(s)=(value)
NEXT VALID
PRS-IDC
IMAGE DETECTOR CTRL PRES.
NO YES
Senographe DS
A
B
C
D
NO
S2100D How To.fm
