3 Click Modify Pads tab
4 Click Modify Pads
5 Sketch the slope arrow on the building pad.
6 With the slope arrow highlighted, click Draw panel
7 For Specify, select either Height at Tail or Slope.
8 Click OK.
9 Click Finish Building Pad.
Related topic
Slope Arrow

Building Pad Properties

You can change the properties of building pad types and building pad instances.

Modifying Building Pad Properties

1 Open a site or plan view.
2 Select the building pad.
3 Click Modify Pads tab
4 Property changes made to a building pad type affect all building pads of this type in the project.
5 When finished, click OK twice.

Building Pad Type Properties

Name
Construction
968 | Chapter 15 Site Design
NOTE Use Tab to cycle through the selection options. Selection options are displayed on the left side
of the status bar.
Edit Boundary tab
If you select Height at Tail, then select a level, and specify a height offset for both the tail
and head of the arrow.
If you select Slope, then select a level, and specify a height offset for the tail, then the input
value for Slope.
on page 685
NOTE Use Tab to cycle through the selection options. Selection options are displayed on the left side
of the status bar.
To change the properties of the building pad instance, change the values in the Instance
Properties dialog.
To change the properties of the building pad type, click Edit Type in the Instance Properties
dialog, and change the properties as desired.
(To create a new building pad type, click Duplicate.)
Description
Edit panel Edit Boundary.
Draw panel
Element panel Element Properties.
Slope Arrow.
Properties.
