Annotation elements help to document the model. For example, dimensions, text notes, and section
tags are annotation elements.
Datum elements are non-physical items that are used to establish project context. For example, levels,
grids, and reference planes are datum elements.
The following drawing includes model elements (walls, doors, planters), annotation elements (dimensions,
text notes), and datum elements (grid lines). For more information, see
element borrowing A Revit function for workshared projects. Element borrowing allows you to edit an
element in a workset that you do not own. If another team member is currently editing the workset, that
team member is the owner of the workset and you must place a request to borrow the element. If no one
owns the workset, permission to borrow is automatically granted.
See Borrowing Elements
element properties Parameters or settings that control the appearance or behavior of elements in a project.
Element properties are the combination of instance parameters and type parameters.
To view or change element properties, select the element in the drawing area, and on the Options Bar, click
(Element Properties). For more information, see
elevation An orthographic view of a vertical part of a building model. Typically, an elevation provides a
side view of a building. Also called an elevation view.
For more information, see
embedded wall A wall that is inserted into another wall of a different type or construction. Embedded walls
are useful, for example, when you need to create a storefront on a building exterior.
The following image shows a curtain wall embedded in a host wall. For more information, see
Walls on page 566.
1394 | Glossary
on page 1198.
Elevation Views on page 85.
Building with Elements
Element Properties Dialog
on page 73.
on page 75.
Embedded
