5 DPort Registers
5.4 Register Summary
Name
System and memory registers
DPORT_PRO_BOOT_REMAP_CTRL_REG
DPORT_APP_BOOT_REMAP_CTRL_REG
DPORT_CACHE_MUX_MODE_REG
Reset and clock registers
DPORT_CPU_PER_CONF_REG
Interrupt matrix registers
DPORT_CPU_INTR_FROM_CPU_0_REG
DPORT_CPU_INTR_FROM_CPU_1_REG
DPORT_CPU_INTR_FROM_CPU_2_REG
DPORT_CPU_INTR_FROM_CPU_3_REG
DPORT_PRO_INTR_STATUS_REG_0_REG
DPORT_PRO_INTR_STATUS_REG_1_REG
DPORT_PRO_INTR_STATUS_REG_2_REG
DPORT_APP_INTR_STATUS_REG_0_REG
DPORT_APP_INTR_STATUS_REG_1_REG
DPORT_APP_INTR_STATUS_REG_2_REG
DPORT_PRO_MAC_INTR_MAP_REG
DPORT_PRO_MAC_NMI_MAP_REG
DPORT_PRO_BB_INT_MAP_REG
DPORT_PRO_BT_MAC_INT_MAP_REG
DPORT_PRO_BT_BB_INT_MAP_REG
DPORT_PRO_BT_BB_NMI_MAP_REG
DPORT_PRO_RWBT_IRQ_MAP_REG
DPORT_PRO_RWBLE_IRQ_MAP_REG
DPORT_PRO_RWBT_NMI_MAP_REG
DPORT_PRO_RWBLE_NMI_MAP_REG
DPORT_PRO_SLC0_INTR_MAP_REG
DPORT_PRO_SLC1_INTR_MAP_REG
DPORT_PRO_UHCI0_INTR_MAP_REG
DPORT_PRO_UHCI1_INTR_MAP_REG
DPORT_PRO_TG_T0_LEVEL_INT_MAP_REG
DPORT_PRO_TG_T1_LEVEL_INT_MAP_REG
DPORT_PRO_TG_WDT_LEVEL_INT_MAP_REG
DPORT_PRO_TG_LACT_LEVEL_INT_MAP_REG
DPORT_PRO_TG1_T0_LEVEL_INT_MAP_REG
DPORT_PRO_TG1_T1_LEVEL_INT_MAP_REG
DPORT_PRO_TG1_WDT_LEVEL_INT_MAP_REG
DPORT_PRO_TG1_LACT_LEVEL_INT_MAP_REG
DPORT_PRO_GPIO_INTERRUPT_MAP_REG
DPORT_PRO_GPIO_INTERRUPT_NMI_MAP_REG
