30 ULP Coprocessor (ULP)
Operand Description - see Figure
Rdst Destination Register R[0-3], results will be stored in this register.
Sel Selected ADC: 0 = SAR ADC1, 1 = SAR ADC2, see Table 30-4.
Sar Mux SARADC Pad [Sar_Mux - 1] is enabled, see Table 30-4.
Table 30-4. Input Signals Measured Using the ADC Instruction
Description
The instruction prompts the taking of measurements with the use of ADC. Pads/signals available for ADC
measurement are provided in Table 30-4.
30.4.12 I2C_RD/I2C_WR – Read/Write I²C
31 28 27
4'd3
Operand Description - see Figure
Sub-addr Slave register address
Data Data to write in I2C_WR operation (not used in I2C_RD operation)
Low High part of bit mask
High Low part of bit mask
I2C Sel Select register
R/W I²C communication direction:
1 - I²C write
0 - I²C read
