30 ULP Coprocessor (ULP)
30.4.1.2 Operations with Immediate Value
31 28 27
4'd7 3'b1
Figure 30-4. Instruction Type — ALU for Operations with Immediate Value
When bits [27:25] of the instruction in Figure
R[0-3] and the immediate value stored in [19:4]. The types of operations depend on the setting of the
instruction's bits [24:21] presented in Table 30-2.
Operand Description - see Figure
ALU_sel Type of ALU operation
Rdst Register R[0-3], destination
Rsrc1 Register R[0-3], source
Imm 16-bit signed value
ALU_sel Instruction
0 ADD
1 SUB
2 AND
3 OR
4 MOVE
5 LSH
6 RSH
Note:
• ADD/SUB operations can be used to set/clear the overflow flag in ALU.
• All ALU operations can be used to set/clear the zero flag in ALU.
30.4.1.3 Operations with Stage Count Register
31 28 27
4'd7 3'b2
Figure 30-5. Instruction Type — ALU for Operations with Stage Count Register
ALU is also able to increment/decrement by a given value, or reset the 8-bit register Stage_cnt. To do so, bits
[27:25] of instruction in Figure
the instruction's bits [24:21] presented in Table 30-3. The Stage_cnt is a separate register and is not a part of
the instruction in Figure 30-5.
Operand Description - see Figure
ALU_sel Type of ALU operation
Stage_cnt Stage count register, a separate register [7:0] used to store variables, such as loop index
Imm 8-bit value
