10 Ethernet Media Access Controller (MAC)
Continued from the previous page...
RX_THRESH_CTRL These two bits control the threshold level of the MTL Receive FIFO. Transfer
(request) to DMA starts when the frame size within the MTL Receive FIFO is larger than the
threshold. 2'b00: 64; 2'b01: 32; 2'b10: 96; 2'b11: 128. (R/W)
OPT_SECOND_FRAME When this bit is set, it instructs the DMA to process the second frame of the
Transmit data even before the status for the first frame is obtained. (R/W)
START_STOP_RX When this bit is set, the Receive process is placed in the Running state. The
DMA attempts to acquire the descriptor from the Receive list and processes the incoming
frames.When this bit is cleared, the Rx DMA operation is stopped after the transfer of the current
frame. (R/W)
Espressif Systems
Register 10.7. DMAOPERATION_MODE_REG (0x0018)
