Espressif ESP32 Technical Reference Manual page 452

16 Motor Control PWM (PWM)
Name
PWM_FH0_CFG0_REG
PWM_FH0_CFG1_REG
PWM_FH0_STATUS_REG
PWM Operator 1 Configuration and Status
PWM_GEN1_STMP_CFG_REG
PWM_GEN1_TSTMP_A_REG
PWM_GEN1_TSTMP_B_REG
PWM_GEN1_CFG0_REG
PWM_GEN1_FORCE_REG
PWM_GEN1_A_REG
PWM_GEN1_B_REG
PWM_DT1_CFG_REG
PWM_DT1_FED_CFG_REG
PWM_DT1_RED_CFG_REG
PWM_CARRIER1_CFG_REG
PWM_FH1_CFG0_REG
PWM_FH1_CFG1_REG
PWM_FH1_STATUS_REG
PWM Operator 2 Configuration and Status
PWM_GEN2_STMP_CFG_REG
PWM_GEN2_TSTMP_A_REG
PWM_GEN2_TSTMP_B_REG
PWM_GEN2_CFG0_REG
PWM_GEN2_FORCE_REG
PWM_GEN2_A_REG
PWM_GEN2_B_REG
PWM_DT2_CFG_REG
PWM_DT2_FED_CFG_REG
PWM_DT2_RED_CFG_REG
PWM_CARRIER2_CFG_REG
Espressif Systems
Description
Actions on PWM0A and PWM0B on
trip events
Software triggers for fault handler ac-
tions
Status of fault events
Transfer status and update method
for time stamp registers A and B
Shadow register for register A
Shadow register for register B
Fault event T0 and T1 handling
Permissives to force PWM1A and
PWM1B outputs by software
Actions triggered by events on
PWM1A
Actions triggered by events on
PWM1B
Dead time type selection and config-
uration
Shadow register for FED
Shadow register for RED
Carrier enable and configuration
Actions on PWM1A and PWM1B on
fault events
Software triggers for fault handler ac-
tions
Status of fault events
Transfer status and updating method
for time stamp registers A and B
Shadow register for register A
Shadow register for register B
Fault event T0 and T1 handling
Permissives to force PWM2A and
PWM2B outputs by software
Actions triggered by events on
PWM2A
Actions triggered by events on
PWM2B
Dead time type selection and config-
uration
Shadow register for FED
Shadow register for RED
Carrier enable and configuration
452
Submit Documentation Feedback
PWM0 PWM1
0x3FF5E068 0x3FF6C068
0x3FF5E06C 0x3FF6C06C R/W
0x3FF5E070 0x3FF6C070
0x3FF5E074 0x3FF6C074
0x3FF5E078 0x3FF6C078
0x3FF5E07C 0x3FF6C07C
0x3FF5E080 0x3FF6C080
0x3FF5E084 0x3FF6C084
0x3FF5E088 0x3FF6C088
0x3FF5E08C 0x3FF6C08C
0x3FF5E090 0x3FF6C090 R/W
0x3FF5E094 0x3FF6C094
0x3FF5E098 0x3FF6C098
0x3FF5E09C 0x3FF6C09C R/W
0x3FF5E0A0 0x3FF6C0A0 R/W
0x3FF5E0A4 0x3FF6C0A4
0x3FF5E0A8 0x3FF6C0A8
0x3FF5E0AC 0x3FF6C0AC
0x3FF5E0B0 0x3FF6C0B0 R/W
0x3FF5E0B4 0x3FF6C0B4
0x3FF5E080 0x3FF6C080
0x3FF5E0BC 0x3FF6C0BC R/W
0x3FF5E0C0 0x3FF6C0C0 R/W
0x3FF5E0C4 0x3FF6C0C4
0x3FF5E0C8 0x3FF6C0C8
0x3FF5E0CC 0x3FF6C0CC R/W
0x3FF5E0D0 0x3FF6C0D0 R/W
0x3FF5E0D4 0x3FF6C0D4
ESP32 TRM (Version 5.2)
Acc
R/W
RO
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
RO
R/W
R/W
R/W
R/W
R/W
R/W
