16 Motor Control PWM (PWM)
31
0 0 0 0 0 0 0
PWM_TIMER1_DIRECTION Current direction of the PWM timer1 counter. 0: increment 1: decrement.
(RO)
PWM_TIMER1_VALUE Current value of the PWM timer1 counter. (RO)
31 26 25
0 0 0 0 0 0 0
PWM_TIMER2_PERIOD_UPMETHOD Updating method for active register of PWM timer2 period. 0:
immediately, 1: update at TEZ, 2: update at sync, 3: update at TEZ or sync. (R/W)
PWM_TIMER2_PERIOD Period shadow register of PWM timer2. (R/W)
PWM_TIMER2_PRESCALE Period of PT2_clk = Period of PWM_clk * (PWM_TIMER2_PRESCALE +
1). (R/W)
Espressif Systems
Register 16.9. PWM_TIMER1_STATUS_REG (0x0020)
