16 Motor Control PWM (PWM)
31
0 0 0 0 0 0 0
PWM_GEN0_A PWM generator 0 time stamp A's shadow register. (R/W)
31
0 0 0 0 0 0 0
PWM_GEN0_B PWM generator 0 time stamp B's shadow register. (R/W)
31
0 0 0 0 0 0 0
PWM_GEN0_T1_SEL Source selection for PWM generator 0 event_t1, taking effect immediately. 0:
fault_event0, 1: fault_event1, 2: fault_event2, 3: sync_taken, 4: none. (R/W)
PWM_GEN0_T0_SEL Source selection for PWM generator 0 event_t0, taking effect immediately,
0: fault_event0, 1: fault_event1, 2: fault_event2, 3: sync_taken, 4: none. (R/W)
PWM_GEN0_CFG_UPMETHOD Updating method for PWM generator 0's active register of config-
uration. When all bits are set to 0: immediately; when bit0 is set to 1: TEZ; when bit1 is set to 1:
TEP; when bit2 is set to 1: sync; when bit3 is set to 1: disable the update. (R/W)
Espressif Systems
Register 16.17. PWM_GEN0_TSTMP_A_REG (0x0040)
