16 Motor Control PWM (PWM)
31
0 0 0 0 0 0 0
PWM_DT1_CLK_SEL Dead time generator 1 clock selection. 0: PWM_clk, 1: PT_clk. (R/W)
PWM_DT1_B_OUTBYPASS S0 in Table 16-5. (R/W)
PWM_DT1_A_OUTBYPASS S1 in Table 16-5. (R/W)
PWM_DT1_FED_OUTINVERT S3 in Table 16-5. (R/W)
PWM_DT1_RED_OUTINVERT S2 in Table 16-5. (R/W)
PWM_DT1_FED_INSEL S5 in Table 16-5. (R/W)
PWM_DT1_RED_INSEL S4 in Table 16-5. (R/W)
PWM_DT1_B_OUTSWAP S7 in Table 16-5. (R/W)
PWM_DT1_A_OUTSWAP S6 in Table 16-5. (R/W)
PWM_DT1_DEB_MODE S8 in Table 16-5; dual-edge B mode. 0: FED/RED take effect on different
paths separately; 1: FED (falling edge delay)/RED (rising edge delay) take effect on B path.
(R/W)
PWM_DT1_RED_UPMETHOD Updating method for RED active register. 0: immediately; when bit0
is set to 1: TEZ; when bit1 is set to 1: TEP; when bit2 is set to 1: sync; when bit3 is set to 1:
disable the update. (R/W)
PWM_DT1_FED_UPMETHOD Updating method for FED active register. 0: immediately; when bit0
is set to 1: TEZ; when bit1 is set to 1: TEP; when bit2 is set to 1: sync; when bit3 is set to 1:
disable the update. (R/W)
31
0 0 0 0 0 0 0
PWM_DT1_FED Shadow register for FED. (R/W)
