Espressif ESP32 Technical Reference Manual page 455

16 Motor Control PWM (PWM)
31
0 0 0 0 0 0 0
PWM_TIMER0_MOD PWM timer0 working mode. 0: freeze, 1: increase mode, 2: decrease mode,
3: up-down mode. (R/W)
PWM_TIMER0_START PWM timer0 start and stop control. 0: if PWM timer0 starts, then stops at
TEZ; 1: if timer0 starts, then stops at TEP; 2: PWM timer0 starts and runs on; 3: timer0 starts and
stops at the next TEZ; 4: timer0 starts and stops at the next TEP. TEP here and below means
the event that happens when the timer equals to period. (R/W)
31
0 0 0 0 0 0 0
PWM_TIMER0_PHASE_DIRECTION 0: increase; 1: decrease. (R/W)
PWM_TIMER0_PHASE Phase for timer reload at sync event. (R/W)
PWM_TIMER1_SYNCO_SEL PWM timer0 sync_out selection. 0: sync_in; 1: TEZ; 2: TEP; otherwise:
sync_out is always 0. (R/W)
PWM_TIMER1_SYNC_SW Toggling this bit will trigger a software sync. (R/W)
PWM_TIMER1_SYNCI_EN When set, timer reloading with phase on sync input event is enabled.
(R/W)
Espressif Systems
Register 16.3. PWM_TIMER0_CFG1_REG (0x0008)
0 0 0 0 0 0 0 0
Register 16.4. PWM_TIMER0_SYNC_REG (0x000c)
21 20 19
0 0 0 0 0
Submit Documentation Feedback
0 0 0 0 0 0 0 0
0
455
5 4 3 2
0 0 0 0 0x0 0x0
4 3 2 1
0 0
ESP32 TRM (Version 5.2)
0
Reset
0
0
Reset
