4 IO_MUX and GPIO Matrix (GPIO, IO_MUX)
Register 4.32. GPIO_FUNCn_OUT_SEL_CFG_REG (n: 0-19, 21-23, 25-27, 32-33) (0x530+0x4*n)
31
0 0 0 0 0 0 0
GPIO_FUNCn_OEN_INV_SEL 1: Invert the output enable signal; 0: do not invert the output enable
signal. (R/W)
GPIO_FUNCn_OEN_SEL 1:
GPIO_ENABLE_REG; 0: use output enable signal from peripheral. (R/W)
GPIO_FUNCn_OUT_INV_SEL 1: Invert the output value; 0: do not invert the output value. (R/W)
GPIO_FUNCn_OUT_SEL Selection control for GPIO output n.
connects peripheral output
GPIO_OUT_REG/GPIO_OUT1_REG and GPIO_ENABLE_REG/GPIO_ENABLE1_REG as the output
value and output enable. (R/W)
4.13.2 IO MUX Registers
The addresses in parenthesis besides register names are the register addresses relative to the IO MUX base
addresses provided in Table
register addresses are listed in Section
