7 SPI Controller (SPI)
7.8 Registers
The addresses in parenthesis besides register names are the register addresses relative to the SPI0/SPI1/SPI2/SPI3
base addresses provided in Table
solute register addresses are listed in Section
31
0 0 0 0 0 0 0
SPI_USR An SPI operation will be triggered when this bit is set. The bit will be cleared once the
operation is done. (R/W)
31
SPI_ADDR_REG It stores the transmitting address when master is in half-duplex mode or QSPI mode.
If the address length is bigger than 32 bits, this register stores the higher 32 bits of address value,
SPI_SLV_WR_STATUS_REG
smaller than 33 bits, this register stores all the address value. The register is in valid only when
SPI_USR_ADDR
