Espressif ESP32 Technical Reference Manual page 485

16 Motor Control PWM (PWM)
31
0 0 0 0 0 0 0
PWM_DT2_RED Shadow register for RED. (R/W)
31
0 0 0 0 0 0 0
PWM_CARRIER2_IN_INVERT When set, invert the input of PWM2A and PWM2B for this submodule.
(R/W)
PWM_CARRIER2_OUT_INVERT When set, invert the output of PWM2A and PWM2B for this sub-
module. (R/W)
PWM_CARRIER2_OSHWTH Width of the first pulse in number of periods of the carrier. (R/W)
PWM_CARRIER2_DUTY Carrier duty selection. Duty = PWM_CARRIER2_DUTY / 8. (R/W)
PWM_CARRIER2_PRESCALE PWM carrier2 clock (PC_clk) prescale value. Period of PC_clk = pe-
riod of PWM_clk * (PWM_CARRIER2_PRESCALE + 1). (R/W)
PWM_CARRIER2_EN When set, carrier2 function is enabled. When cleared, carrier2 is bypassed.
(R/W)
Espressif Systems
Register 16.53. PWM_DT2_RED_CFG_REG (0x00d0)
0 0 0 0 0 0 0 0
Register 16.54. PWM_CARRIER2_CFG_REG (0x00d4)
0 0 0 0 0 0 0 0
Submit Documentation Feedback
16 15
0
14 13 12 11
0 0 0 0 0 0
485
0
8 7 5 4 1
0 0
ESP32 TRM (Version 5.2)
0
Reset
0
0
Reset
