1 System and Memory
1.3 Functional Description
1.3.1 Address Mapping
Each of the two Harvard Architecture Xtensa LX6 CPUs has 4 GB (32-bit) address space. Address spaces are
symmetric between the two CPUs.
Addresses below 0x4000_0000 are serviced using the data bus. Addresses in the range 0x4000_0000 ~
0x4FFF_FFFF are serviced using the instruction bus. Finally, addresses over and including 0x5000_0000 are
shared by the data and instruction bus.
The data bus and instruction bus are both little-endian: for example, byte addresses 0x0, 0x1, 0x2, 0x3 access
the least significant, second least significant, second most significant, and the most significant bytes of the
32-bit word stored at the 0x0 address, respectively. The CPU can access data bus addresses via aligned or
non-aligned byte, half-word and word read-and-write operations. The CPU can read and write data through the
instruction bus, but only in a word aligned manner; non-word-aligned access will cause a CPU exception.
Each CPU can directly access embedded memory through both the data bus and the instruction bus, external
memory which is mapped into the address space (via transparent caching & MMU), and peripherals. Table
illustrates address ranges that can be accessed by each CPU's data bus and instruction bus.
Some embedded memories and some external memories can be accessed via the data bus or the instruction
bus. In these cases, the same memory is available to either of the CPUs at two address ranges.
Bus Type
Low Address
0x0000_0000
Data 0x3F40_0000
Data 0x3F80_0000
0x3FC0_0000
Data 0x3FF0_0000
Data 0x3FF8_0000
Instruction 0x4000_0000
Instruction 0x400C_2000
0x40C0_0000
Data / Instruction 0x5000_0000
0x5000_2000
1.3.2 Embedded Memory
The Embedded Memory consists of four segments: internal ROM (448 KB), internal SRAM (520 KB), RTC FAST
memory (8 KB) and RTC SLOW memory (8 KB).
The 448 KB internal ROM is divided into two parts: Internal ROM 0 (384 KB) and Internal ROM 1 (64 KB). The 520
KB internal SRAM is divided into three parts: Internal SRAM 0 (192 KB), Internal SRAM 1 (128 KB), and Internal
SRAM 2 (200 KB). RTC FAST Memory and RTC SLOW Memory are both implemented as SRAM.
Espressif Systems
Table 1-1. Address Mapping
Boundary Address
High Address
0x3F3F_FFFF
0x3F7F_FFFF
0x3FBF_FFFF
0x3FEF_FFFF
0x3FF7_FFFF
0x3FFF_FFFF
0x400C_1FFF
0x40BF_FFFF
0x4FFF_FFFF
0x5000_1FFF
0xFFFF_FFFF
26
Submit Documentation Feedback
Size Target
Reserved
4 MB External Memory
4 MB External Memory
3 MB Reserved
512 KB Peripheral
512 KB Embedded
ory
776 KB Embedded
ory
11512 KB External Memory
244 MB Reserved
8 KB Embedded
ory
Reserved
ESP32 TRM (Version 5.2)
1-1
Mem-
Mem-
Mem-
