4 IO_MUX and GPIO Matrix (GPIO, IO_MUX)
Signal Input Signal
195 I2S1I_H_ENABLE
196 -
197 -
198 U2RXD_in
199 U2CTS_in
200 emac_mdc_i
201 emac_mdi_i
202 emac_crs_i
203 emac_col_i
204 pcmfsync_in
205 pcmclk_in
206 pcmdin
207 -
208 -
209 -
210 -
211 -
212 -
213 -
214 -
215 -
224 -
225 -
226 -
227 -
228 -
Direct I/O in IO_MUX "YES" means that this signal is also available directly via IO_MUX. To apply the GPIO Matrix
to these signals, their corresponding SIG_IN_SEL register must be cleared.
4.10 IO_MUX Pad List
Table 4-3 shows the IO_MUX functions for each I/O pad:
GPIO Pad Name Function 0
0 GPIO0 GPIO0
1 U0TXD U0TXD
2 GPIO2 GPIO2
3 U0RXD U0RXD
4 GPIO4 GPIO4
5 GPIO5 GPIO5
6 SD_CLK SD_CLK
7 SD_DATA_0 SD_DATA0
8 SD_DATA_1 SD_DATA1
9 SD_DATA_2 SD_DATA2
10 SD_DATA_3 SD_DATA3
