Espressif ESP32 Technical Reference Manual page 476

16 Motor Control PWM (PWM)
31
0 0 0 0 0 0 0
PWM_DT1_RED Shadow register for RED. (R/W)
31
0 0 0 0 0 0 0
PWM_CARRIER1_IN_INVERT When set, invert the input of PWM1A and PWM1B for this submodule.
(R/W)
PWM_CARRIER1_OUT_INVERT When set, invert the output of PWM1A and PWM1B for this submod-
ule. (R/W)
PWM_CARRIER1_OSHWTH Width of the first pulse in number of periods of the carrier. (R/W)
PWM_CARRIER1_DUTY Carrier duty selection. Duty = PWM_CARRIER1_DUTY/8. (R/W)
PWM_CARRIER1_PRESCALE PWM carrier1 clock (PC_clk) prescale value. Period of PC_clk = period
of PWM_clk * (PWM_CARRIER1_PRESCALE + 1). (R/W)
PWM_CARRIER1_EN When set, carrier1 function is enabled. When cleared, carrier1 is bypassed.
(R/W)
Espressif Systems
Register 16.39. PWM_DT1_RED_CFG_REG (0x0098)
0 0 0 0 0 0 0 0
Register 16.40. PWM_CARRIER1_CFG_REG (0x009c)
0 0 0 0 0 0 0 0
Submit Documentation Feedback
16 15
0
14 13 12 11
0 0 0 0 0 0
476
0
8 7 5 4 1
0 0
ESP32 TRM (Version 5.2)
0
Reset
0
0
Reset
