31 Low-Power Management (RTC_CNTL)
31
28
27
26
0
0
0
0
0
0
0
RTC_CNTL_RTC_RDY_FOR_WAKEUP The value 1 indicates the RTC is ready to be triggered by any
wakeup source. (RO)
RTC_CNTL_MAIN_STATE_IN_IDLE Indicates the RTC state.
• 0: the chip can be either
– in sleep modes.
– entering sleep modes. In this case, wait until
is set, then you can wake up the chip.
– exiting sleep mode. In this case,
come 1.
• 1: the chip is not in sleep modes (i.e. running normally).
(RO)
31
30
29
0
0
0
0
0
0
0
RTC_CNTL_XTL_EXT_CTR_EN Enable control XTAL with external pads. (R/W)
RTC_CNTL_XTL_EXT_CTR_LV 0: power down XTAL at high level, 1: power down XTAL at low level.
(R/W)
Espressif Systems
Register 31.19. RTC_CNTL_LOW_POWER_ST_REG (0x00C0)
