4 IO_MUX and GPIO Matrix (GPIO, IO_MUX)
31
x x x x x x x
RTCIO_RTC_GPIO_STATUS_INT GPIO0-17 interrupt status.
etc. This register should be used together with RTCIO_RTC_GPIO_PINn_INT_TYPE in RT-
CIO_RTC_GPIO_PINn_REG. 1: corresponding interrupt; 0: no interrupt. (R/W)
Register 4.42. RTCIO_RTC_GPIO_STATUS_W1TS_REG (0x001C)
31
x x x x x x x
RTCIO_RTC_GPIO_STATUS_INT_W1TS GPIO0-17 interrupt set register. For every bit that is 1 in the
value written here, the corresponding bit in RTCIO_RTC_GPIO_STATUS_INT will be set. (WO)
Register 4.43. RTCIO_RTC_GPIO_STATUS_W1TC_REG (0x0020)
31
x x x x x x x
RTCIO_RTC_GPIO_STATUS_INT_W1TC GPIO0-17 interrupt clear register. For every bit that is 1 in the
value written here, the corresponding bit in RTCIO_RTC_GPIO_STATUS_INT will be cleared. (WO)
