How to Programme

LCP keys

[Menu]
Select one of the following modes:
•
Status
•
Quick Setup
•
Main Menu
1
Status
2
Menu
OK
On
3
Warn.
Alarm
Hand
4 O
on
Illustration 2.21 LCP Keys
Status Mode
Displays the status of the frequency converter or the
motor.
If an alarm occurs the NLCP automatically switches to
status mode.
A number of alarms can be displayed.
NOTICE
Parameter copy is not possible with LCP 101 Numerical
Local Control Panel.
MG20O702
Programming Guide
Setup
Quick Main
Setup Menu
Auto
Reset
on
Danfoss A/S © Rev. 2014-01-21 All rights reserved.
22.8
Illustration 2.22 Status Mode
A 17
Illustration 2.23 Alarm
Main Menu/Quick Setup
is used for programming all parameters or only the
parameters in the Quick Menu (see also description of the
LCP 102 earlier in chapter 2.3 How to Programme on the
Numerical LCP).
When the value flashes, press [
parameter values.
Select Main Menu by pressing [Menu] a number of times.
Select the parameter group [xx-__] and press [OK]
Select the parameter [__-xx] and press [OK]
If the parameter is an array parameter select the array
number and press [OK]
Select the wanted data value and press [OK]
Parameters with functional choices display values such as
[1], [2], etc. For a description of the different choices, see
the individual description of the parameters in
chapter 3 Parameter Description
[Back]
for stepping backwards
▲ ▼
[ ] [ ] are used for manoeuvring between commands and
within parameters.
P 2-03
Status Quick
Menu
Setup
Illustration 2.24 Main Menu/Quick Setup
2.3.1 LCP Keys
Keys for local control are found at the bottom of the LCP.
rpm
Setup 1
Setup 1
▲ ▼
] or [ ] to change
Setup 1
Main
Menu
23
