How to Programme
A 17
Illustration 2.23 Alarm
Main Menu/Quick Setup
is used for programming all parameters or only the
parameters in the Quick Menu (see also description of the
LCP 102 earlier in 2.1 The Graphical and Numerical Local
Control Panels).
When the value flashes, press [
parameter values.
Select Main Menu by pressing [Menu] a number of times.
Select the parameter group [xx-__] and press [OK]
Select the parameter [__-xx] and press [OK]
If the parameter is an array parameter select the array
number and press [OK]
Select the wanted data value and press [OK]
Parameters with functional choices display values such as
[1], [2], etc. For a description of the different choices, see
the individual description of the parameters in 3 Parameter
Descriptions
[Back]
for stepping backwards
▲ ▼
[ ] [ ] are used for manoeuvring between commands and
within parameters.
P 2-03
Status Quick
Menu Setup
Illustration 2.24 Main Menu/Quick Setup

2.1.16 LCP Keys

Keys for local control are found at the bottom of the LCP.
Hand
O
on
Illustration 2.25 LCP Keys
®
VLT AutomationDrive FC 301/302 Programming Guide
Setup 1
▲ ▼
] or [ ] to change
Setup 1
Main
Menu
Auto
Reset
on
MG33MH02 - Rev. 2013-09-30
[Hand On]
enables control of the frequency converter via the LCP.
[Hand On] also starts the motor and it is now possible to
enter the motor speed data with the arrow keys. The key
can be selected as [1] Enable or [0] Disable via 0-40 [Hand
on] Key on LCP.
External stop signals activated with control signals or a
serial bus overrides a 'start' command via the LCP.
The following control signals are still active when [Hand
On] is activated:
•
[Hand On] - [Off] - [Auto On]
•
Reset
•
Coasting stop inverse
•
Reversing
•
Set-up select lsb - Set-up select msb
•
Stop command from serial communication
•
Quick stop
•
DC brake
[Off]
stops the connected motor. The key can be selected as [1]
Enable or [0] Disable via 0-41 [Off] Key on LCP.
If no external stop function is selected and the [Off] key is
inactive the motor can be stopped by disconnecting the
voltage.
[Auto On]
enables the frequency converter to be controlled via the
control terminals and/or serial communication. When a
start signal is applied on the control terminals and/or the
bus, the frequency converter starts. The key can be
selected as [1] Enable or [0] Disable via 0-42 [Auto on] Key
on LCP.
NOTICE
An active HAND-OFF-AUTO signal via the digital inputs
has higher priority than the control keys [Hand On]
[Auto On].
[Reset]
is used for resetting the frequency converter after an alarm
(trip). It can be selected as [1] Enable or [0] Disable via
0-43 [Reset] Key on LCP.

2.1.17 Initialisation to Default Settings

Initialise the frequency converter to default settings in 2
ways.
Recommended initialisation (via 14-22 Operation Mode)
1. Select 14-22 Operation Mode
2. Press [OK]
3. Select [2] Initialisation
2 2
