Lcp Keys; Initialisation To Default Settings - Danfoss VLT AutomationDrive FC 302 Programming Manual

How to Program
A 17
Illustration 2.23 Alarm
Main Menu/Quick Set-up
is used for programming all parameters or only the
parameters in the Quick Menu (see also description of the
LCP 102 in chapter 2.1 The Graphical and Numerical Local
Control Panels).
When the value flashes, press [
parameter values.
Press [Menu] to select Main Menu.
Select the parameter group [xx-__] and press [OK].
Select the parameter [__-xx] and press [OK].
If the parameter is an array parameter, select the array
number and press [OK].
Select the wanted data value and press [OK].
Parameters with functional options display values such as
[1], [2], etc. For a description of the different options, see
the individual description of the parameters in
chapter 3 Parameter Descriptions.
[Back]
for stepping backwards.
▲ ▼
[ ] [ ] are used for manoeuvring between commands and
within parameters.
P 2-03
Status Quick
Menu Setup
Illustration 2.24 Main Menu/Quick Setup

2.1.16 LCP Keys

Keys for local control are found at the bottom of the LCP.
Hand
O
on
Illustration 2.25 LCP Keys
MG33MJ02
Programming Guide
Setup 1
▲ ▼
] or [ ] to change
Setup 1
Main
Menu
Auto
Reset
on
Danfoss A/S © Rev. 10/2014 All rights reserved.
[Hand On]
enables control of the frequency converter via the LCP.
[Hand On] also starts the motor and it is now possible to
enter the motor speed data with the navigation keys. The
key can be selected as [1] Enable or [0] Disable via
0-40 [Hand on] Key on LCP.
External stop signals activated with control signals or a
serial bus overrides a start command via the LCP.
The following control signals are still active when [Hand
On] is activated:
•
[Hand On] - [Off] - [Auto On]
•
Reset
•
Coasting stop inverse
•
Reversing
•
Set-up select lsb - Set-up select msb
•
Stop command from serial communication
•
Quick stop
•
DC brake
[Off]
stops the connected motor. The key can be selected as [1]
Enable or [0] Disable via parameter 0-41 [Off] Key on LCP.
If no external stop function is selected and the [Off] key is
inactive, the motor can be stopped by disconnecting the
voltage.
[Auto On]
enables control of the frequency converter via the control
terminals and/or serial communication. When a start signal
is applied on the control terminals and/or the bus, the
frequency converter starts. The key can be selected as [1]
Enable or [0] Disable via parameter 0-42 [Auto on] Key on
LCP.
NOTICE
An active HAND-OFF-AUTO signal via the digital inputs
has higher priority than the control keys [Hand On]
[Auto On].
[Reset]
is used for resetting the frequency converter after an alarm
(trip). It can be selected as [1] Enable or [0] Disable via
parameter 0-43 [Reset] Key on LCP.
