RM0351
15.5.5

QUADSPI data length register (QUADSPI_DLR)

Address offset: 0x0010
Reset value: 0x0000 0000
31 30 29 28
rw rw rw rw
15 14 13 12
rw rw rw rw
Bits 31:0 DL[31: 0]: Data length
15.5.6 QUADSPI communication configuration register (QUADSPI_CCR)
Address offset: 0x0014
Reset value: 0x0000 0000
31 30 29 28
DDRM Res. Res.
SIOO
rw rw
15 14 13 12
ABMODE ADSIZE
rw rw rw rw
27 26 25 24
rw rw rw rw
11 10 9 8
rw rw rw rw
Number of data to be retrieved (value+1) in indirect and status-polling modes. A value
no greater than 3 (indicating 4 bytes) should be used for status-polling mode.
All 1s in indirect mode means undefined length, where QUADSPI will continue until the
end of memory, as defined by FSIZE.
0x0000_0000: 1 byte is to be transferred
0x0000_0001: 2 bytes are to be transferred
0x0000_0002: 3 bytes are to be transferred
0x0000_0003: 4 bytes are to be transferred
...
0xFFFF_FFFD: 4,294,967,294 (4G-2) bytes are to be transferred
0xFFFF_FFFE: 4,294,967,295 (4G-1) bytes are to be transferred
0xFFFF_FFFF: undefined length -- all bytes until the end of Flash memory (as defined
by FSIZE) are to be transferred. Continue reading indefinitely if FSIZE = 0x1F.
This field has no effect when in memory-mapped mode (FMODE = 10).
This field can be written only when BUSY = 0.
27 26 25 24
DMODE
FMODE[1:0]
rw rw rw rw
11 10 9 8
ADMODE IMODE
rw rw rw rw
DocID024597 Rev 3
23 22 21
DL[31:16]
rw rw rw
7 6 5
DL[15:0]
rw rw rw
23 22 21
Res.
rw rw
7 6 5
rw rw rw
Quad-SPI interface (QUADSPI)
20 19 18
rw rw rw
4 3 2
rw rw rw
20 19 18
DCYC[4:0]
rw rw rw
4 3 2
INSTRUCTION[7:0]
rw rw rw
17 16
rw rw
1 0
rw rw
17 16
ABSIZE
rw rw
1 0
rw rw
419/1693
