RM0351
ECC result registers (FMC_ECCR)
Address offset: 0x94
Reset value: 0x0000 0000
This register contain the current error correction code value computed by the ECC
computation modules of the FMC NAND controller. When the CPU reads the data from a
NAND Flash memory page at the correct address (refer to
the error correction code (ECC) in NAND Flash
NAND Flash memory are processed automatically by the ECC computation module. When
X bytes have been read (according to the ECCPS field in the FMC_PCR registers), the CPU
must read the computed ECC value from the FMC_ECC registers. It then verifies if these
computed parity data are the same as the parity value recorded in the spare area, to
determine whether a page is valid, and, to correct it otherwise. The FMC_ECCR register
should be cleared after being read by setting the ECCEN bit to '0'. To compute a new data
block, the ECCEN bit must be set to '1'.
31 30 29
r r r
15 14 13
r r r
Bits 31:0 ECC: ECC result
ECCPS[2:0]
28 27 26 25
r r r r
12 11 10 9
r r r r
This field contains the value computed by the ECC computation logic.
the contents of these bit fields.

Table 80. ECC result relevant bits

000
001
010
011
100
101
Flexible static memory controller (FSMC)
memory), the data read/written from/to the
24 23 22
ECCx
r r r
8 7 6
ECCx
r r r
Page size in bytes
256
512
1024
2048
4096
8192
DocID024597 Rev 3
Section 14.6.6: Computation of
21 20 19 18
r r r r
5 4 3 2
r r r r
Table 80
ECC bits
ECC[21:0]
ECC[23:0]
ECC[25:0]
ECC[27:0]
ECC[29:0]
ECC[31:0]
17 16
r r
1 0
r r
describes
