Advanced encryption standard hardware accelerator (AES)
25.14.3

AES data input register (AES_DINR)

Address offset: 0x08
Reset value: 0x0000 0000
31 30 29 28
rw rw rw rw
15 14 13 12
rw rw rw rw
Bits 31:0 DINR[31:0]: Data input register
This register must be written 4 times during the input phase:
– In mode 1 (encryption), 4 words must be written which represent the plain text from MSB to LSB.
– In mode 2 (key derivation), This register is not used because this mode concerns only derivative key
calculation starting from the AES_KEYRx register.
– In mode 3 (decryption) and 4 (Key derivation + decryption), 4 words must be written which represent
the cipher text MSB to LSB.
Note: This register must be accessed with 32-bit data width.
25.14.4 AES data output register (AES_DOUTR)
Address offset: 0x0C
Reset value: 0x0000 0000
31 30 29 28
r r r r
15 14 13 12
r r r r
Bits 31:0 DOUTR[31:0]: Data output register
This register is read only.
Once the CCF flag (computation complete flag) is set, reading this data register 4 times gives access
to the 128-bit output results:
– In mode 1 (encryption), the 4 words read represent the cipher text from MSB to LSB.
– In mode 2 (key derivation), there is no need to read this register because the derivative key is
located in the AES_KEYRx registers.
– In mode 3 (decryption) and mode 4 (key derivation + decryption), the 4 words read represent the
plain text from MSB to LSB.
Note: This register must be accessed with 32-bit data width.
742/1693
27 26 25 24
rw rw rw rw
11 10 9 8
rw rw rw rw
27 26 25 24
DOUTR[31:16]
r r r r
11 10 9 8
DOUTR[15:0]
r r r r
DocID024597 Rev 3
23 22 21
DINR[31:16]
rw rw rw
7 6 5
DINR[15:0]
rw rw rw
23 22 21
r r r
7 6 5
r r r
20 19 18 17
rw rw rw rw
4 3 2 1
rw rw rw rw
20 19 18 17
r r r r
4 3 2 1
r r r r
RM0351
16
rw
0
rw
16
r
0
r
