RM0351
Bit 2 Reserved, must be kept at reset value.
Bit 1 JSWSTART: Start a conversion of the injected group of channels
0: Writing '0' has no effect.
1: Writing '1' makes a request to convert the channels in the injected conversion group, causing
JCIP to become '1' at the same time. If JCIP=1 already, then writing to JSWSTART has no effect.
Writing '1' has no effect if JSYNC=1.
This bit is always read as '0'.
Bit 0 DFEN: DFSDM enable
0: DFSDMx is disabled. All conversions of given DFSDMx are stopped immediately and all DFSDMx
functions are stopped.
1: DFSDMx is enabled. If DFSDMx is enabled, then DFSDM starts operating according to its setting.
Data is cleared by setting DFEN=0:
–register DFSDMx_ISR is set to the reset state
–register DFSDMx_AWSR is set to the reset state
21.7.2

DFSDM control register 2 (DFSDMx_CR2)

Address offset: 0x100 * (x+1) + 0x004, x = 0...3
Reset value: 0x0000 0000
31 30 29
Res. Res. Res. Res.
15 14 13
rw rw rw
Bits 31:24 Reserved, must be kept at reset value.
Bits 23:16 AWDCH[7:0]: Analog watchdog channel selection
These bits select the input channel to be guarded continuously by the analog watchdog
AWDCH[y] = 0: Analog watchdog is disabled on channel y
AWDCH[y] = 1: Analog watchdog is enabled on channel y
Bits 15:8 EXCH[7:0]: Extremes detector channel selection
These bits select the input channels to be taken by the Extremes detector
EXCH[y] = 0: Extremes detector does not accept data from channel y
EXCH[y] = 1: Extremes detector accepts data from channel y
Bit 7 Reserved, must be kept at reset value.
Bit 6 CKABIE: Clock absence interrupt enable
0: Detection of channel input clock absence interrupt is disabled
1: Detection of channel input clock absence interrupt is enabled
Please see the explanation of CKABF[7:0] in DFSDMx_ISR.
Note: CKABIE is present only in DFSDM0_CR2 register (filter x=0)
28 27 26 25
Res. Res. Res.
12 11 10 9
EXCH[7:0]
rw rw rw rw
DocID024597 Rev 3
Digital filter for sigma delta modulators (DFSDM)
24 23 22 21
Res.
rw rw rw
8 7 6 5
CKAB
Res. SCDIE AWDIE
IE
rw rw rw
20 19 18 17
AWDCH[7:0]
rw rw rw rw
4 3 2 1
ROVR JOVRI REOC
IE E IE
rw rw rw rw
16
rw
0
JEOCI
E
rw
