RM0351
Bits 31:24 MEMHIZ[7:0]: Common memory x data bus Hi-Z time
Bits 23:16 MEMHOLD[7:0]: Common memory hold time
Bits 15:8 MEMWAIT[7:0]: Common memory wait time
Bits 7:0 MEMSET[7:0]: Common memory x setup time
Attribute memory space timing registers (FMC_PATT)
Address offset: 0x8C
Reset value: 0xFCFC FCFC
The FMC_PATT read/write register contains the timing information for NAND Flash memory
bank. It is used for 8-bit accesses to the attribute memory space of the NAND Flash for the
last address write access if the timing must differ from that of previous accesses (for
Ready/Busy management, refer to
31 30 29
rw rw rw
15 14 13
rw rw rw
Defines the number of HCLK clock cycles during which the data bus is kept Hi-Z after the
start of a NAND Flash write access to common memory space on socket. This is only valid
for write transactions:
0000 0000: 1 HCLK cycle
1111 1110: 255 HCLK cycles
1111 1111: reserved.
Defines the number of HCLK clock cycles during which the address is held (and data for
write accesses) after the command is deasserted (NWE, NOE), for NAND Flash read or
write access to common memory space on socket x:
0000 0000: reserved.
0000 0001: 1 HCLK cycle
1111 1110: 254 HCLK cycles
1111 1111: reserved.
Defines the minimum number of HCLK (+1) clock cycles to assert the command (NWE,
NOE), for NAND Flash read or write access to common memory space on socket. The
duration of command assertion is extended if the wait signal (NWAIT) is active (low) at the
end of the programmed value of HCLK:
0000 0000: reserved
0000 0001: 2HCLK cycles (+ wait cycle introduced by deasserting NWAIT)
1111 1110: 255 HCLK cycles (+ wait cycle introduced by deasserting NWAIT)
1111 1111: reserved.
Defines the number of HCLK (+1) clock cycles to set up the address before the command
assertion (NWE, NOE), for NAND Flash read or write access to common memory space on
socket x:
0000 0000: 1 HCLK cycle
1111 1110: 255 HCLK cycles
1111 1111: reserved
28 27 26 25
ATTHIZ
rw rw rw rw
12 11 10 9
ATTWAIT
rw rw rw rw
Flexible static memory controller (FSMC)
Section 14.6.5: NAND Flash prewait
24 23 22
rw rw rw
8 7 6
rw rw rw
DocID024597 Rev 3
functionality).
21 20 19 18
ATTHOLD
rw rw rw rw
5 4 3 2
ATTSET
rw rw rw rw
17 16
rw rw
1 0
rw rw
