To perform an ECC computation:
1. Enable the ECCEN bit in the FMC_PCR register.
2. Write data to the NAND Flash memory page. While the NAND page is written, the ECC
block computes the ECC value.
3. Read the ECC value available in the FMC_ECCR register and store it in a variable.
4. Clear the ECCEN bit and then enable it in the FMC_PCR register before reading back
the written data from the NAND page. While the NAND page is read, the ECC block
computes the ECC value.
5. Read the new ECC value available in the FMC_ECCR register.
6. If the two ECC values are the same, no correction is required, otherwise there is an
ECC error and the software correction routine returns information on whether the error
can be corrected or not.
14.6.7

NAND Flashcontroller registers

NAND Flash control registers (FMC_PCR)
Address offset: 0x80
Reset value: 0x0000 0018
31 30 29
Res. Res. Res. Res.
15 14 13
TAR
rw rw rw
Bits 31:20 Reserved, must be kept at reset value
Bits 19:17 ECCPS[2:0]: ECC page size.
Bits 16:13 TAR[3:0]: ALE to RE delay.
Note: SET is MEMSET or ATTSET according to the addressed space.
