ST STM32L4x6 Reference Manual page 748

Advanced encryption standard hardware accelerator (AES)
31 30 29 28
rw rw rw rw
15 14 13 12
rw rw rw rw
Bits 31:0 KEYR7[31:0]: Data output register (MSB key [255:224])
Same description as AES_KEYR0 for the key[255:224].
Note: The key registers from 4 to 7 are used only when 256-bit key length is selected. These
registers have no effect when 128-bit key length is selected (only key registers from 0 to 3
are used).
748/1693
27 26 25 24
KEYR731:16]
rw rw rw rw
11 10 9 8
rw rw rw rw
DocID024597 Rev 3
23 22 21
rw rw rw
7 6 5
KEYR7[15:0]
rw rw rw
20 19 18 17
rw rw rw rw
4 3 2 1
rw rw rw rw
RM0351
16
rw
0
rw
