ST STM32L4x6 Reference Manual page 381

RM0351
31 30 29
Res. Res. ACCMOD
rw
15 14 13
rw rw rw
Bits 31:30 Reserved, must be kept at reset value
Bits 29:28 ACCMOD[1:0]: Access mode
Specifies the asynchronous access modes as shown in the timing diagrams. These bits are
taken into account only when the EXTMOD bit in the FMC_BCRx register is 1.
00: access mode A
01: access mode B
10: access mode C
11: access mode D
Bits 27:24 DATLAT[3:0]: (see note below bit descriptions): Data latency for synchronous memory
For synchronous access with read/write burst mode enabled (BURSTEN / CBURSTRW bits
set), defines the number of memory clock cycles (+2) to issue to the memory before
reading/writing the first data:
This timing parameter is not expressed in HCLK periods, but in FMC_CLK periods.
For asynchronous access, this value is don't care.
0000: Data latency of 2 CLK clock cycles for first burst access
1111: Data latency of 17 CLK clock cycles for first burst access (default value after reset)
Bits 23:20 CLKDIV[3:0]: Clock divide ratio (for FMC_CLK signal)
Defines the period of FMC_CLK clock output signal, expressed in number of HCLK cycles:
0000: Reserved
0001: FMC_CLK period = 2 × HCLK periods
0010: FMC_CLK period = 3 × HCLK periods
1111: FMC_CLK period = 16 × HCLK periods (default value after reset)
In asynchronous NOR Flash, SRAM or PSRAM accesses, this value is don't care.
Note: Refer to
28 27 26 25
DATLAT
rw rw rw rw
12 11 10 9
DATAST
rw rw rw rw
Section 14.5.5: Synchronous transactions
DocID024597 Rev 3
Flexible static memory controller (FSMC)
24 23 22 21
CLKDIV
rw rw rw rw
8 7 6 5
ADDHLD
rw rw rw rw
20 19 18
BUSTURN
rw rw rw
4 3 2
ADDSET
rw rw rw
for FMC_CLK divider ratio formula)
17 16
rw rw
1 0
rw rw
381/1693
