RM0351
Bit 8 QSPISMEN Quad SPI memory interface clocks enable during Sleep and Stop modes
Bits 7:1 Reserved, must be kept at reset value.
Bit 0 FMCSMEN: Flexible memory controller clocks enable during Sleep and Stop modes
1. This register only configures the clock gating, not the clock source itself. Most of the peripherals are clocked by a single
clock (AHB or APB clock), which is always disabled in Stop mode. In this case setting the bit has no effect in Stop mode.
6.4.25
APB1 peripheral clocks enable in Sleep and Stop modes register 1
(RCC_APB1SMENR1)
Address: 0x78
Reset value: 0xF2FE CA3FAccess: no wait state, word, half-word and byte access
31
30
29
28
LPTIM1
OPAMP
DAC1
PWR
SMEN
SMEN
SMEN
SMEN
rw
rw
rw
rw
15
14
13
12
SPI3
SPI2
Res.
Res.
SMEN
SMEN
rw
rw
Bit 31 LPTIM1SMEN: Low power timer 1 clocks enable during Sleep and Stop modes
Bit 30 OPAMPSMEN: OPAMP interface clocks enable during Sleep and Stop modes
Bit 29 DAC1SMEN: DAC1 interface clocks enable during Sleep and Stop modes
Bit 28 PWRSMEN: Power interface clocks enable during Sleep and Stop modes
Bits 27:26 Reserved, must be kept at reset value.
Set and cleared by software.
0: QUADSPI clocks disabled by the clock gating
1: QUADSPI clocks enabled by the clock gating
Set and cleared by software.
0: FMC clocks disabled by the clock gating
1: FMC clocks enabled by the clock gating
27
26
25
CAN1
Res.
Res.
SMEN
rw
11
10
9
LCD
WWDG
Res.
SMEN
SMEN
rw
rw
Set and cleared by software.
0: LPTIM1 clocks disabled by the clock gating
1: LPTIM1 clocks enabled by the clock gating
Set and cleared by software.
0: OPAMP interface clocks disabled by the clock gating
1: OPAMP interface clocks enabled by the clock gating
Set and cleared by software.
0: DAC1 interface clocks disabled by the clock gating
1: DAC1 interface clocks enabled by the clock gating
Set and cleared by software.
0: Power interface clocks disabled by the clock gating
1: Power interface clocks enabled by the clock gating
(1)
during Sleep and Stop modes
(1)
during Sleep and Stop modes
24
23
22
I2C3
I2C2
I2C1
Res.
SMEN
SMEN
SMEN
rw
rw
8
7
6
TIM7
Res.
Res.
Res.
SMEN
(1)
(1)
DocID024597 Rev 3
Reset and clock control (RCC)
(1)
during Sleep and Stop modes
(1)
during Sleep and Stop modes
21
20
19
UART5
UART4
USART3
SMEN
SMEN
SMEN
rw
rw
rw
5
4
3
TIM6
TIM5
TIM4
SMEN
SMEN
SMEN
rw
rw
rw
during Sleep and Stop modes
during Sleep and Stop modes
(1)
during Sleep and Stop modes
(1)
during Sleep and Stop modes
(1)
during Sleep and Stop modes
(1)
during Sleep and Stop modes
(1)
during Sleep and Stop modes
(1)
during Sleep and Stop modes
18
17
16
USART2
Res.
SMEN
rw
rw
2
1
0
TIM3
TIM2
SMEN
SMEN
rw
rw
rw
237/1693
253
