Reset and clock control (RCC)
6.4.5

PLLSAI1 configuration register (RCC_PLLSAI1CFGR)

Address offset: 0x10
Reset value: 0x0000 1000
Access: no wait state, word, half-word and byte access
This register is used to configure the PLLSAI1 clock outputs according to the formulas:
• f(VCOSAI1 clock) = f(PLL clock input) × (PLLSAI1N / PLLM)
• f(PLLSAI1_P) = f(VCOSAI1 clock) / PLLSAI1P
• f(PLLSAI1_Q) = f(VCOSAI1 clock) / PLLSAI1Q
• f(PLLSAI1_R) = f(VCOSAI1 clock) / PLLSAI1R
31 30 29
Res. Res. Res. Res.
15 14 13
Res.
rw rw
Bits 31:27 Reserved, must be kept at reset value.
Bits 26:25 PLLSAI1R[1:0]: PLLSAI1 division factor for PLLADC1CLK (ADC clock)
Bit 24 PLLSAI1REN: PLLSAI1 PLLADC1CLK output enable
Bit 23 Reserved, must be kept at reset value.
206/1693
28 27 26 25
Res. PLLSAI1R[1:0]
rw rw
12 11 10 9
PLLSAI1N[6:0]
rw rw rw rw
Set and cleared by software to control the frequency of the SAI1PLL output clock
PLLADC1CLK. This output can be selected as ADC clock. These bits can be written only if
SAI1PLL is disabled.
PLLADC1CLK output clock frequency = VCOSAI1 frequency / PLLSAI1R with PLLSAI1R =
2, 4, 6, or 8
00: PLLSAI1R = 2
01: PLLSAI1R = 4
10: PLLSAI1R = 6
11: PLLSAI1R = 8
Set and reset by software to enable the PLLADC1CLK output of the SAI1PLL (used as clock
for ADC).
In order to save power, when the PLLADC1CLK output of the SAI1PLL is not used, the value
of PLLSAI1REN should be 0.
0: PLLADC1CLK output disable
1: PLLADC1CLK output enable
24 23 22
PLL
SAI1 Res. PLLSAI1Q[1:0]
REN
rw rw
8 7 6
Res. Res.
rw
DocID024597 Rev 3
21 20 19 18
PLL
SAI1 Res. Res.
QEN
rw rw
5 4 3 2
Res. Res. Res. Res.
RM0351
17 16
PLL
PLL
SAI1
SAI1P
PEN
rw rw
1 0
Res. Res.
